Tektronix AWG70001A Technical Reference page 81

Performance Test
Ch 2 Markers
AWG70000A Series and AWGSYNC01 Technical Reference
Minimum
M1 +
High level 1.185 V
–75 mV
–1.065 V
Low level 0.735 V
–75 mV
–1.615 V
M1 –
High level 1.185 V
–75 mV
–1.065 V
Low level 0.735 V
–75 mV
–1.615 V
M2 +
High level 1.185 V
–75 mV
–1.065 V
Low level 0.735 V
–75 mV
–1.615 V
M2 –
High level 1.185 V
–75 mV
–1.065 V
Low level 0.735 V
–75 mV
–1.615 V
Incoming Outgoing
Performance tests
Maximum
1.615 V
+75 mV
–0.735 V
1.065 V
+75 mV
–1.185 V
1.615 V
+75 mV
–0.735 V
1.065 V
+75 mV
–1.185 V
1.615 V
+75 mV
–0.735 V
1.065 V
+75 mV
–1.185 V
1.615 V
+75 mV
–0.735 V
1.065 V
+75 mV
–1.185 V
2–37
