Electrical specifications
Table 1-33: Electrical specifications
Characteristic
System
Number of AWG70001A or
AWG70002A instruments
supported
Output to Output Skew
(typical)
Repeatability
(typical)
Random Jitter on Clock Pattern
(typical)
Total Jitter on Random Pattern
(typical)
Calibration
Connector
Number of inputs
Input Impedance
Clock
Clock Output
Number of Outputs
Connector
Output Impedance
Output Amplitude (typical)
Frequency Range
Clock Input
Connector
Input Impedance
1–22
Description
4
All instruments must be the same model
±10 ps
≤5 ps
0.315 ps rms
13 ps
p-p
SMA at the Front Panel
4
50 Ω
The external clock output is a copy of an external input clock into the sync hub. This output is
used to drive the external clock input of the AWG.
4
SMA on rear-panel
50 Ω AC coupled
+5 dBm to +10 dBm
6.25 GHz to 12.5 GHz
The external clock input is used to create the DAC sample clock. This clock must always operate
in the octave range specified below.
SMA on rear-panel
50 Ω AC coupled
AWG70000A Series and AWGSYNC01 Technical Reference
