AWGSYNC01
Synchronization Hub
Safety and Installation Manual
*P071329201*
071-3292-01
www.valuetronics.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AWGSYNC01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tektronix AWGSYNC01

  • Page 1 AWGSYNC01 Synchronization Hub Safety and Installation Manual *P071329201* 071-3292-01 www.valuetronics.com...
  • Page 2 www.valuetronics.com...
  • Page 3 AWGSYNC01 Synchronization Hub Safety and Installation Manual Revision A www.tektronix.com 071-3292-01 www.valuetronics.com...
  • Page 4 Tektronix. All rights reserved. Licensed software products are owned by Tektronix or its subsidiaries or suppliers, and are protected by national copyright laws and international treaty provisions. Tektronix products are covered by U.S. and foreign patents, issued and pending. Information in this publication supersedes that in all previously published material.
  • Page 5 Tektronix, with shipping charges prepaid. Tektronix shall pay for the return of the product to Customer if the shipment is to a location within the country in which the Tektronix service center is located. Customer shall be responsible for paying all shipping charges, duties, taxes, and any other charges for products returned to any other locations.
  • Page 6 www.valuetronics.com...
  • Page 7: Table Of Contents

    Connect the instruments ......................... Enable the Slave AWG70000 instruments ..................Configure the Master AWG70000 ....................Calibrate (deskew) the AWG70000 output channels ..............Output synchronized signals ......................Specifications General specifications ........................Inputs, outputs ..........................Physical characteristics ......................... Environment ..........................AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 8 Table of Contents AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 9: Important Safety Information

    Read the safety sections of the other component manuals for warnings and cautions related to operating the system. When incorporating this equipment into a system, the safety of that system is the responsibility of the assembler of the system. AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 10 Provide a safe working environment. Always place the product in a location convenient for viewing the display and indicators. Be sure your work area meets applicable ergonomic standards. Consult with an ergonomics professional to avoid stress injuries. Use only the Tektronix rackmount hardware specified for this product. AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 11: Service Safety Summary

    These terms may appear in this manual: WARNING. Warning statements identify conditions or practices that could result in injury or loss of life. CAUTION. Caution statements identify conditions or practices that could result in damage to this product or other property. AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 12: Terms On The Product

    (This symbol may also be used to refer the user to ratings in the manual.) The following symbols may appear on the product: AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 13: Compliance Information

    This product is intended for use in nonresidential areas only. Use in residential areas may cause electromagnetic interference. Emissions which exceed the levels required by this standard may occur when this equipment is connected to a test object. AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 14: Safety Compliance

    Measurement, Control, and Laboratory Use – Part 1: General Requirements. U.S. nationally recognized UL 61010-1. Safety Requirements for Electrical Equipment for ■ testing laboratory listing Measurement, Control, and Laboratory Use – Part 1: General Requirements. viii AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 15 The area is protected from direct sunshine, rain, or direct wind. ■ Pollution Degree 4. Pollution that generates persistent conductivity through conductive dust, rain, or snow. Typical outdoor locations. AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 16 NOTE. Only mains power supply circuits have an overvoltage category rating. Only measurement circuits have a measurement category rating. Other circuits within the product do not have either rating. Mains overvoltage Overvoltage Category II (as defined in IEC 61010-1) category rating AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 17: Environmental Compliance

    European Union requirements according to Directives 2002/96/EC and 2006/66/EC on waste electrical and electronic equipment (WEEE) and batteries. For information about recycling options, check the Support/Service section of the Tektronix Web site (www.tektronix.com). Restriction of hazardous This product is classified as an industrial monitoring and control instrument, and...
  • Page 18 Compliance Information AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 19: Preface

    ■ Synchronize to within 10 ps ■ Triggers all channels to same resolution ■ Where to get more information For additional operating information, refer to the AWGSYNC01 topics on your AWG70000 series instrument application help. AWGSYNC01 Synchronization Hub xiii www.valuetronics.com...
  • Page 20 Preface AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 21: Install The Instrument

    Install the instrument Unpack the instrument and check that you received all items listed as Standard Accessories, and any optional accessories you may have ordered. Check the Tektronix Web site (www.tektronix.com) for the most current information. Standard accessories Table 1: Standard accessories...
  • Page 22: Options

    WARNING. To reduce the risk of fire and shock, ensure that the mains supply voltage fluctuations do not exceed 10% of the operating voltage range. Source voltage and frequency Power consumption 100 VAC to 240 VAC, 50/60 Hz 110 W AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 23: Power-On And Power-Off Procedures

    Power-on and power-off procedures 1. Connect the AC power cord to the rear of the instrument. 2. Push the front-panel power button to power on the instrument. 3. Reverse steps 1 and 2 to power off the instrument. AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 24 Install the instrument AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 25: Operating Basics

    Input for the synchronization clock signal. If using the Master AWG70000 instrument as the clock source, then connect the Clock Out port on ■ the Master instrument to this connector on the AWGSYNC01. Use the supplied phase-matched blue clock cable provided with the instrument. ■...
  • Page 26: Connect The Instruments

    NOTE. There is no Ethernet connection on the AWGSYNC01. The AWGSYNC01 is controlled by the Master AWG70000 instrument. Connect the instruments The following diagrams show how to connect the AWGSYNC01 to two or more AWG70000 instruments. CAUTION. Use proper electrostatic discharge (ESD) handling procedures when connecting cables to the AWGSYNC01 and AWG70000 instruments to prevent damage.
  • Page 27 Operating basics Figure 1: Rear panel connections: clock source = Master AWG70000 AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 28 Operating basics Figure 2: Rear panel connections: clock source = external clock signal AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 29: Enable The Slave Awg70000 Instruments

    Operating basics Enable the Slave AWG70000 instruments Prerequisite: All instruments are connected to the AWGSYNC01. (See Connect the AWGSYNC01 to AWG70000 instruments.) NOTE. You can use the Master AWG70000 UI to connect or disconnect from individual Slave AWG70000 instruments as long as you have enabled synchronization on the Slave AWG70000 instruments.
  • Page 30 Operating basics 4. Click Enable. 5. Click Change Configuration. Select the slave ports to enable. AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 31: Calibrate (Deskew) The Awg70000 Output Channels

    Master AWG70000. Prerequisites: ■ All instruments are connected to the AWGSYNC01 (see Connect the instruments). All Slave AWG70000 instruments have been enabled (from each Slave ■ instrument and from the Master instrument).
  • Page 32 Operating basics Figure 3: Connect the calibration deskew cables (front panel) AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 33 Operating basics 1. Use the supplied matched silver calibration cables to connect the Calibration ports on the front of the AWGSYNC01 to the same CH1+ or CH1– output on all AWG70000 Master and Slave instruments. The order of the connections is important.
  • Page 34: Output Synchronized Signals

    3. Set the clock, trigger, and other controls. 4. Enable the Master AWG70000 to play sequences and waveforms. 5. When the trigger event occurs, the Master AWG70000 signals all enabled Slave AWG70000 instruments, and itself, to simultaneously output their respective waveforms. AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 35: Specifications

    Synchronous trigger mode: 30,880 / (2 * fclk) ±20 ns fclk is the frequency of the DAC sampling clock The DAC sampling clock frequency is displayed on the clock settings tab when the external clock output is enabled. AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 36 15-pin D-sub female connector on rear panel Input levels 3.3 V LVCMOS 5 V TTL compliant (input impedance pull up to 5 V by 1 kΩ resistor) Strobe Polarity: Data is clocked in on negative edge Minimum pulse width: 64 ns AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 37 1, 6, 8, 9, 14, 15 Data bit 0, input Data bit 1, input Data bit 2, input Data bit 3, input Strobe input Data bit 4, input Data bit 5, input Data bit 6, input Data bit 7, input AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 38: Physical Characteristics

    Up to 3,000 meters (9,843 feet) Derate maximum operating temperature by 1 °C per 300 meters above 1500 meters Nonoperating Up to 12,000 meters (39,370 feet) Regulatory Safety UL61010-1, CAN/CSA-22.2, No.61010-1, EN61010-1, IEC61010-1 EMC Emissions IEC61326, EN55011 (Class A), IEC61000-3-2, IEC61000-3-3 AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 39 Environment (cont.) Specifications EMC Immunity IEC61326, IEC61000-4-2/3/4/5/6/11 Regional certifications Europe: EN61326 Australia/New Zealand: AS/NZS 2064 AWGSYNC01 Synchronization Hub www.valuetronics.com...
  • Page 40 Specifications Environment (cont.) AWGSYNC01 Synchronization Hub www.valuetronics.com...
