Table 1-11: Phase noise with jitter reduction, AWG70002A operating at 8 GS/s

Offset 100 MHz
100 Hz –110 dBc/Hz
1 kHz –127 dBc / Hz
10 kHz –134 dBc/Hz
100 kHz
–134 dBc/Hz
1 MHz –142 dBc/Hz
10 MHz –154 dBc/Hz

Table 1-12: Phase noise with jitter reduction, AWG70002A operating at 16 GS/s

Offset 100 MHz
100 Hz –112 dBc/Hz
1 kHz –128 dBc / Hz
10 kHz
–134 dBc/Hz
100 kHz –133 dBc/Hz
1 MHz –141 dBc/Hz
10 MHz –154 dBc/Hz

Table 1-13: Phase noise without jitter reduction, AWG70001A operating at 49.998998 GS/s

Offset 100 MHz
100 Hz –110 dBc/Hz
1 kHz
–125 dBc/Hz
10 kHz –130 dBc/Hz
100 kHz –126 dBc/Hz
1 MHz –139 dBc/Hz
10 MHz –145 dBc/Hz
Table 1-14: Phase noise without jitter reduction, AWG70001A & AWG70002A operating at 24.998998 GS/s
Offset
100 Hz
1 kHz
10 kHz
100 kHz
1 MHz
10 MHz
AWG70000A Series and AWGSYNC01 Technical Reference
1 GHz
–89 dBc/Hz
–109 dBc / Hz
–115 dBc/Hz
–113 dBc/Hz
–121 dBc/Hz
–149 dBc/Hz
Analog output frequency
1 GHz
–90 dBc/Hz
–109 dBc / Hz
–116 dBc/Hz
–113 dBc/Hz
–122 dBc/Hz
–150 dBc/Hz
1 GHz
–89 dBc/Hz
–105 dBc/Hz
–110 dBc/Hz
–106 dBc/Hz
–119 dBc/Hz
–128 dBc/Hz
100 MHz
–104 dBc/Hz
–124 dBc/Hz
–130 dBc/Hz
–126 dBc/Hz
–131 dBc/Hz
–142 dBc/Hz
Analog output frequency
2 GHz
–83 dBc/Hz
–102 dBc / Hz
–108 dBc/Hz
–106 dBc/Hz
–114 dBc/Hz
–144 dBc/Hz
2 GHz 3 GHz
–87 dBc/Hz –82 dBc/Hz
–103 dBc / Hz –99 dBc / Hz
–110 dBc/Hz –106 dBc/Hz
–108 dBc/Hz –104 dBc/Hz
–116 dBc/Hz –113 dBc/Hz
–147 dBc/Hz –143 dBc/Hz
Analog output frequency
10 GHz
–69 dBc/Hz
–84 dBc/Hz
–94 dBc/Hz
–89 dBc/Hz
–104 dBc/Hz
–111 dBc/Hz
Analog output frequency
1 GHz
–92 dBc/Hz
–105 dBc/Hz
–111 dBc/Hz
–106 dBc/Hz
–122 dBc/Hz
–129 dBc/Hz
Specifications
3 GHz
–80 dBc/Hz
–99 dBc / Hz
–107 dBc/Hz
–104 dBc/Hz
–112 dBc/Hz
–141 dBc/Hz
4 GHz
–80 dBc/Hz
–97 dBc / Hz
–104 dBc/Hz
–101 dBc/Hz
–110 dBc/Hz
–140 dBc/Hz
16 GHz
–67 dBc/Hz
–82 dBc/Hz
–89 dBc/Hz
–85 dBc/Hz
–100 dBc/Hz
–106 dBc/Hz
10 GHz
–74 dBc/Hz
–83 dBc/Hz
–93 dBc/Hz
–89 dBc/Hz
–104 dBc/Hz
–109 dBc/Hz
1–9
