Tektronix AWG70001A Technical Reference page 39

Table 1-33: Electrical specifications (cont.)
Characteristic
Input Amplitude (typical)
Frequency Range (typical)
Sync Clock Output
Connector
Output Impedance
Output Amplitude (typical)
Frequency
Trigger Input
Number of Inputs
Slope / Polarity
Connector
Input Impedance
Input Voltage Range
Input Minimum Amplitude
(typical)
Threshold Range
Threshold Resolution
Threshold Accuracy (typical)
Trigger Minimum Pulse Width
(typical)
Trigger Delay to Analog Output
(typical)
Trigger Asynchronous Jitter
(typical)
Trigger Synchronous Jitter
(typical)
AWG70000A Series and AWGSYNC01 Technical Reference
Description
+5 dBm to +10 dBm
6.25 GHz to 12.5 GHz
SMA on rear-panel
50 Ω AC coupled
1.0 ±0.15 V into 50 Ω
p-p
Clock Output ÷ 80
2
Positive or negative selectable
SMA on rear-panel
1 k Ω or 50 Ω selectable
When 1 k is selected: –10 V to +10 V
When 50 Ω is selected: <5 V
0.5 V
p-p
–5.0 V to +5.0 V
0.1 V
±5% of setting + 0.1 V
When 1 kΩ is selected: 20 ns
When 50 Ω is selected: 20 ns
Synchronous trigger mode: 30,800 / (2 * sampling clock) + 20 ns ±20 ns
80 / sampling clock frequency
Clock In = 12.5 GHz:
300 fs rms, 4.2 ps RJ BER@10-12
p-p
Variable Reference In = 156.25 MHz:
400 fs rms, 5.6 ps RJ BER@10-12
p-p
Fixed Reference In = 10 MHz:
1.7 ps rms, 23.8 ps RJ BER@10-12
p-p
Sample rate = 25 GS/s
Trigger input impedance = 50
RMS
AWGSYNC01
1–23
