Table 1-7: SFDR, AWG70002A operating at 8 GS/s
Analog channel In band performance
output frequency measured across
DC – 2.6 GHz DC –2.6 GHz
DC – 3.2 GHz DC – 3.2 GHz
1 Measured with a balun, excluding harmonics.

Table 1-8: SFDR, AWG70002A operating at 16 GS/s

Analog channel In band performance
output frequency measured across
100 MHz DC – 1 GHz
0 – 500 MHz DC – 500 MHz
DC – 1 GHz DC – 1 GHz
DC – 2 GHz DC – 2 GHz
DC – 3.5 GHz DC –3.5 GHz
3.5 – 4.5 GHz 3.5 – 4.5 GHz
4.5 – 6.4 GHz 4.5 – 6.4 GHz
1
Measured with a balun, excluding harmonics.

Table 1-9: Phase noise with jitter reduction, AWG70001A operating at 50 GS/s

Offset 100 MHz
100 Hz –116 dBc/Hz
1 kHz –134 dBc/Hz
10 kHz –136 dBc/Hz
100 kHz
–138 dBc/Hz
1 MHz –150 dBc/Hz
10 MHz –156 dBc/Hz
Table 1-10: Phase noise with jitter reduction, AWG70001A & AWG70002A operating at 25 GS/s
Offset
100 Hz
1 kHz
10 kHz
100 kHz
1 MHz
10 MHz
1–8
1 (cont.)
Specification
–55 dBc
–47 dBc
1
Specification
–80 dBc
–68 dBc
–62 dBc
–60 dBc
–57 dBc
–42 dBc
–52 dBc
1 GHz
–94 dBc/Hz
–116 dBc/Hz
–119 dBc/Hz
–118 dBc/Hz
–132 dBc/Hz
–157 dBc/Hz
100 MHz
–115 dBc/Hz
–134 dBc/Hz
–138 dBc/Hz
–138 dBc/Hz
–150 dBc/Hz
–155 dBc/Hz
Adjacent band
performance
measured across
DC – 4 GHz
DC – 4 GHz
Adjacent band
performance
measured across
DC – 3 GHz
DC – 1.5 GHz
DC – 3 GHz
DC – 6 GHz
DC – 8 GHz
DC – 8 GHz
DC – 8 GHz
Analog output frequency
10 GHz
–75 dBc/Hz
–95 dBc/Hz
–101 dBc/Hz
–99 dBc/Hz
–112 dBc/Hz
–138 dBc/Hz
Analog output frequency
1 GHz
–95 dBc/Hz
–115 dBc/Hz
–121 dBc/Hz
–118 dBc/Hz
–132 dBc/Hz
–157 dBc/Hz
AWG70000A Series and AWGSYNC01 Technical Reference
Specification
–52 dBc
–47 dBc
Specification
–72 dBc
–66 dBc
–63 dBc
–58 dBc
–40 dBc
–42 dBc
–42 dBc
16 GHz
–70 dBc/Hz
–91 dBc/Hz
–96 dBc/Hz
–96 dBc/Hz
–108 dBc/Hz
–130 dBc/Hz
10 GHz
–76 dBc/Hz
–86 dBc/Hz
–102 dBc/Hz
–100 dBc/Hz
–113 dBc/Hz
–138 dBc/Hz
