Table 1-3: Sample Clock Generator; Table 1-4: Analog Output - Tektronix AWG70001A Technical Reference

Table 1-3: Sample clock generator

Characteristics
Instrument / Option
AWG70001A Option 150
AWG70002A Option 225
AWG70002A Option 216
AWG70002A Option 208
Resolution
Phase adjustment
Range
Resolution

Table 1-4: Analog output

Characteristics
Connector type
Number of outputs
Type of outputs
ON/OFF control
Output impedance
VSWR
AWG70001A
AWG70002A
Amplitude
Range
Resolution
DC accuracy (warranted)
Amplitude flatness
AWG70001A
AWG70002A
AWG70000A Series and AWGSYNC01 Technical Reference
Description
Sampling rate control range
1.49 kS/s to 50 GS/s
1.49 kS/s to 25 GS/s
1.49 kS/s to 16 GS/s
1.49 kS/s to 8 GS/s
With jitter reduction: 3 digits
Without jitter reduction: 8 digits
Used to manually align the outputs with other generators or instruments.
-10,800° to +10,800°
1°
Description
Aeroflex/Weinschel Planar Crown Universal Connector System with SMA female adapter
AWG70001A: 1
AWG70002A: 2
(+) and (–) complementary output
Independent control for each analog output complementary pair
50 Ω
DC to 5 GHz = 1.32:1
5 GHz to 10 GHz = 1.52:1
10 GHz to 20 GHz = 1.73:1
DC to 5 GHz = 1.61:1
5 GHz to 10 GHz = 1.61:1
Independent control for each channel
0.25 V to 0.5 V into 50 Ω single-ended
p-p p-p
0.5 V to 1.0 V into 100 Ω differential
p-p p-p
1 mV
±(2% of amplitude + 1 mV)
Flatness is measured as the deviation from the ideal sin(x)/x response curve of the DAC at the
specified sample rate. The response is mathematically removed from the measured data.
+1.8 dB to –1.8 dB up to 10 GHz
+1.8 dB to –3 dB from 10 GHz to 15 GHz
+0.8 dB to –1.5 dB up to 10 GHz
Specifications
1–3
