Performance tests
– Marker low level accuracy
CH 1 Markers M2 + and
M2 – accuracy
AWG70002A marker
accuracy
2–34
The marker low level accuracy is tested using the PV_DC_Plus.wfmx file.
25. In the Waveform List window, select (drag and drop) the PV_DC_Plus.wfmx
waveform to the work space.
26. Repeat steps 15 through 20 to complete the low level accuracy test for the
M1 – Marker output.
27. Repeat steps 7 through 26 for CH 1 Markers M2 + and M2 – outputs.
28. If you are testing an AWG70002A, repeat the marker test (steps 7 through 27)
for the Channel 2 marker outputs.
29. Press the All Outputs On/Off button on the instrument to turn off all the
outputs.
30. Disconnect the test setup.
