Introduction Parameter x.00
description format
Menu 9 contains two programmable logic block functions (which can be used to produce any type of 2 input logic gate, with or without a delay), a
motorised potentiometer function and a binary sum block.
The programmable logic functions are active only if both the sources are routed to a valid parameter.
NOTE
The motorised potentiometer or binary sum functions are only active if the output destination is routed to a valid unprotected parameter. If only the
indicator parameter is required, the destination parameter should be routed to an unused valid parameter.
9.01 Logic function 1 output indicator
9.02 Logic function 2 output indicator
Bit SP
Coding
1
Range 0 or 1
Update rate 21 ms
Indicates the output state of the programmable logic function. The output of the logic function can be routed to the digital output if required, by setting
the appropriate digital output source in menu 8.
9.03

Motorised pot output

Bit SP
Coding
Range ±100.0 %
Update rate 21 ms
9.04

Logic function 1 source 1

Bit SP
Coding
Range Pr 0.01 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
This source parameter and Pr 9.14 define the inputs for source 1 of the programmable logic functions.
Only bit parameters can be programmed into these inputs.
If one or both inputs to the logic function are invalid, then the logic output will always be 0.
9.05

Logic function 1 source 1 invert

Bit SP
Coding
1
Range 0 or 1
Default 0
Update rate 21 ms
Setting this parameter and Pr 9.15 to a 1 causes the input sense of the logic functions to be inverted.
9.06

Logic function 1 source 2

Bit SP
Coding
Range Pr 0.01 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
This source parameter and Pr 9.16 defines the inputs for source 2 of the programmable logic functions.
Only bit parameters can be programmed into these inputs.
If one or both inputs to the logic function are invalid, then the logic output will always be 0.
Commander SK Advanced User Guide
Issue Number: 2
Parameter Keypad and CT Modbus
display
FI DE Txt VM DP ND
1
FI DE Txt VM DP ND
1 1
FI DE Txt VM DP ND
2
FI DE Txt VM DP ND
FI DE Txt VM DP ND
2
www.controltechniques.com
User
CT Soft
RTU programming
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1 1
Advanced parameter
Menu 0
descriptions
PS
PS
1
PS
1
PS
PS
1
Menu 9
