Menu 15 Introduction Parameter x.00
15.42

Analog input 1 invert (terminal T2)

Bit SP
Coding
1
Range 0 to 1
Default 0
Update rate Background read
This parameter can be used to invert the analog input reference (i.e. multiply the input scaling result by -1)
15.43

Analog input 1 destination (Terminal T2)

Bit SP
Coding
Range Pr 1.01 to Pr 21.51
Default Pr 0.00
Update rate Drive read on reset
Only non-bit parameters that are not protected can be controlled by analog inputs. If a non-valid parameter is programmed to the destination of an
analog input, the input is not routed anywhere. After a modification to this parameter, the destination is only changed when a reset is performed.
15.44

Maximum drive encoder reference

Bit SP
Coding
Range 0 to 32000 rpm
Default 1500
Update rate Background read
15.45

Drive encoder reference scaling

Bit SP
Coding
Range 0.000 to 4.000
Default 1.000
Update rate Background read
15.46 Drive encoder reference monitor
Bit SP
Coding
Range -100% to +100%
Update rate Background write
15.47 Drive encoder reference destination
Bit SP
Coding
Range Pr 1.01 to Pr 21.51
Default Pr 0.00
Update rate Drive read on reset
This parameter may be routed to any non-protected drive parameter.
After a modification to this parameter, the destination is only changed when a reset is performed.
154
Parameter Keypad and
description format display
FI DE Txt VM DP ND RA NC
FI DE Txt VM DP ND RA NC
2
FI DE Txt VM DP ND RA NC
FI DE Txt VM DP ND RA NC
3
FI DE Txt VM DP ND RA NC
1 1
FI DE Txt VM DP ND RA NC
1 2
www.controltechniques.com
CT Modbus User
CT Soft
RTU programming
NV PT US RW BU PS
1 1
NV PT US RW BU PS
1 1 1 1
NV PT US RW BU PS
1 1 1
NV PT US RW BU PS
1 1 1
NV PT US RW BU PS
1
NV PT US RW BU PS
1 1 1 1
Commander SK Advanced User Guide
Advanced parameter
Menu 0
descriptions
Issue Number: 2
