Introduction Parameter x.00
description format
3. OR Run forward and Run reverse are both active and have been for 60ms.
The drive can then be restarted by activating the necessary bits to give a normal start. This means that the drive cannot restart automatically after a
trip, for example, by pressing the stop key.
Sequencer latching enabled (Pr 6.40 = 1)
If the stop key is pressed when the stop key is enabled (Pr 6.12 = 1) or when the drive is tripped the sequencer run is removed, and so the drive stops
or remains stopped respectively. The sequencer run can only then be reapplied after at least on of the following conditions occurs.
1. Run forward, Run reverse and Run sequencing bits all zero after the latches
2. OR Not stop sequencing bit is zero
3. OR the drive is disabled via Pr 6.15 or Pr 6.29
4. OR Run forward and Run reverse are both active and have been for 60ms.
The drive can then be restarted by activating the necessary bits to give a normal start. This means that the drive cannot restart automatically after a
trip, for example, by pressing the stop key. Note that Run forward and Run reverse together will reset the stop key condition, but the latches
associated with Run forward and Run reverse must then be reset before the drive can be restarted.
6.13

Function key mode

Bit SP
Coding
Range 0 to 5
Default 0
Update rate Background read
On the LCD keypad:
This parameter enables the Fwd/Rev key to operate in keypad mode.
On the LED keypad:
0: No Function
1: Forward/Reverse toggle
2: Run Reverse
3: Jog
4: Hand off auto
5: Function
6.14

Disable auto-reset on enable

Bit SP
Coding
1
Range 0 or 1
Default 0
Update rate 2 ms
0: Auto reset on enable enabled
1: Auto reset on enable disabled
If this parameter is set to 1, the automatic reset on the toggle of the enable terminal of the drive is disabled.
6.15

Drive enable

Bit SP
Coding
1
Range 0 or 1
Default 1
Update rate 2 ms
0: Drive disabled
1: Drive enabled
Setting this parameter to 0 will disable the drive. It must be at 1 for the drive to run.
6.16

Electricity cost per kWh

Bit SP
Coding
Range 0.0 to 600.0 Currency/kWh
Default 0.0
Update rate Background
When this parameter is set up correctly for the local currency, Pr 6.26 will give an instantaneous read out of running cost.
Commander SK Advanced User Guide
Issue Number: 2
Parameter Keypad and CT Modbus
display
FI DE Txt VM DP ND
FI DE Txt VM DP ND
FI DE Txt VM DP ND
FI DE Txt VM DP ND
1
www.controltechniques.com
User
CT Soft
RTU programming
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
Advanced parameter
Menu 0
descriptions
PS
PS
PS
1
PS
1
Menu 6
73
