Menu 3 Introduction Parameter x.00
9.4

Menu 3: Speed sensing thresholds and frequency input and output

Table 9-5 Menu 3 parameters: single line descriptions
Parameter
3.01 Not used
3.02 Not used
3.03 Not used
3.04 Not used
3.05 Zero speed threshold
3.06 At speed window
3.07 Not used
3.08 Not used
3.09 Not used
3.10 Not used
3.11 Not used
3.12 Not used
3.13 Not used
3.14 Not used
3.15 Not used
3.16 Not used
3.17 Frequency output or PWM output scaling
3.18 Maximum output frequency
3.19 Not used
3.20 Not used
3.21 Not used
3.22 Hard frequency reference
3.23 Hard frequency reference selector
3.24 Not used
3.25 Not used
3.26 Not used
3.27 Not used
3.28 Not used
3.29 Position
3.30 Not used
3.31 Not used
3.32 Position counter reset
3.33 Position scaling numerator
3.34 Position scaling denominator
3.35 Not used
3.36 Not used
3.37 Not used
3.38 Not used
3.39 Not used
3.40 Not used
3.41 Not used
3.42 Not used
3.43 Maximum reference frequency
3.44 Frequency reference scaling
3.45 Frequency reference
