Introduction Parameter x.00
4

Keypad and display

The keypad and display are used for the following:
• Displaying the operating status of the drive
• Displaying a fault or trip code
• Reading and changing parameter values
• Stopping, starting and resetting the drive
Figure 4-1 Keypad and display
M
4.1

Programming keys

The MODE key is used to change the mode of operation of the drive.
M
The UP and DOWN keys are used to select parameters and edit their values. In keypad mode, they are used to increase and decrease the
speed of the motor.
4.2

Control keys

The START key is used to start the drive in keypad mode.
The STOP/RESET key is used to stop and reset the drive in keypad mode. It can also be used to reset the drive in terminal mode.
4.3

Selecting and changing parameters

NOTE
This procedure is written from the first power up of the drive and assumes no terminals have been connected, no parameters have been changed and
no security has been set.
Figure 4-2
Hold
for 2s
Press and
M M M
release
PARAMETER VIEW MODE
Parameter number flashing
M
PARAMETER EDIT MODE
Parameter number flashing
When in Status mode, pressing and holding the
10
Parameter Keypad and
description format display
STATUS MODE
or
Press and
hold for 2s
/ /
/
Select parameter to view
Press or
Parameters
saved
Change parameter value
Press or
MODE key for 2 seconds will change the display from displaying a speed indication to displaying
M
www.controltechniques.com
User
CT Modbus RTU
programming
M
4 mins
timeout
M
Advanced parameter
CT Soft Menu 0
Commander SK Advanced User Guide
Issue Number: 2
descriptions
