Status Relay Invert; Digital I/O Read Word - Control Techniques Commander SK Advanced User's Manual

Introduction Parameter x.00
description format
8.16 Unused parameter
8.17

Status relay invert

Bit SP
Coding
1
Range 0 or 1
Default 0
Update rate 2 ms
Setting this parameter to a 1 causes the relay sense to be inverted.
8.18 to 8.19 Unused parameters
8.20

Digital I/O read word

Bit SP
Coding
Range 0 to 95
Update rate Background
This word is used to determine the status of the digital I/O by reading one parameter.
Pr 8.20 contains a binary value 'xx'. This binary value is determined by the state of Pr 8.01 to Pr 8.07. So for example, if all terminals were active the
value displayed in Pr 8.20 would be the sum of the binary values shown in the table, i.e. 95.
Binary value
Digital I/O
for xx
1 Terminal B3
2 Terminal B4
4 Terminal B5
8 Terminal B6
16 Terminal B7
64 Terminal T5/T6
8.21 Terminal B3 digital input destination/output source
8.22 Terminal B4 digital input destination
8.23 Terminal B5 digital input destination
8.24 Terminal B6 digital input destination
8.25 Terminal B7 digital input destination
Bit SP
Coding
Destination: Pr 1.01 to Pr 21.51
Range
Source: Pr 0.01 to Pr 21.51
Update rate Read on drive reset
Parameter
8.21 Terminal B3 digital input destination/output source
8.22 Terminal B4 digital input destination
8.23 Terminal B5 digital input destination
8.24 Terminal B6 digital input destination
8.25 Terminal B7 digital input destination
The terminal configuration is changed using Pr 6.04.
Destination parameters define the parameter each of the programmable inputs is to control. Only bit parameters which are not protected can be
controlled by the programmable digital inputs. If a non-valid parameter is programmed, the digital input is not routed anywhere.
Source parameters define the parameter to be represented by the digital output terminal. Only bit parameters can be selected as a source for a digital
output. If a non-valid parameter is programmed, then the digital output will remain in the inactive state.
8.26 Unused parameter
