Menu 1 Introduction Parameter x.00
1.41 Analog reference 2 select
1.42 Preset reference select
1.43 Keypad reference select
1.44 Precision reference select
1.45 Preset select bit 0
1.46 Preset select bit 1
1.47 Preset select bit 2
Bit SP
Coding
1
Default 0
Update rate 5ms
These bits are provided for control by logic input terminals for external reference selection (see Pr 1.14 on page 26, and Pr 1.15 on page 27).
Pr 1.41 Analog reference 2 select (lowest priority)
Pr 1.42 Preset reference select
Pr 1.43 Keypad reference select
Pr 1.44 Precision reference select (highest priority)
If more than one of these parameters is active, the highest priority take precedence.
1.48 Unused parameter
1.49

Reference selected indicator

Bit SP
Coding
Range 1 to 5
Update rate 5ms
Indicates the reference currently being selected.
1: Analog reference 1 selected
2: Analog reference 2 selected
3: Preset reference selected
4: Keypad reference selected
5: precision reference selected
1.50

Preset reference selected indicator

Bit SP
Coding
Range 1 to 8
Update rate 5ms
Indicates the preset currently being selected. If Pr 1.49 = 1 or 2 then a value of 1 indicates that one of the analog references is being selected.
1.51

Power-up keypad reference

Bit SP
Coding
Range 0 to 2
Default 0
Update rate N/A
Selects the value of the keypad reference on power-up.
Value Display Function
0 0 keypad reference is zero
1 LASt keypad reference is the last used value
2 PrS1 keypad reference is copied from Preset speed 1 (Pr 1.21)
