Menu 15 Introduction Parameter x.00
15.14 Terminal T5 digital input invert
15.15 Terminal T6 digital input invert
15.16 Terminal T7 digital input invert
Bit SP
Coding
1
Range 0 to 1
Default 0
Update rate Background read
Setting these parameters to a 1 causes the input sense to the destination parameter to be inverted.
15.17

Relay invert

Bit SP
Coding
1
Range 0 to 1
Default 0
Update rate Background read
Setting this parameter to a 1 causes the relay sense to be inverted.
15.18 Unused parameter
15.19

Real time clock day light saving mode

Bit SP
Coding
1
Range 0 to 1
Default 0
Update rate Background read
0 Real time clock normal operation
1 Real time clock + 1 hour
15.20 Digital I/O read word
Bit SP
Coding
Range 0 to 255
Update rate Background write
This word is used to determine the status of the digital I/O by reading one parameter.
Pr 15.20 contains a binary value 'xx'. This binary value is determined by the state of Pr 15.04 to Pr 15.07. So for example, if all terminals were active
the value displayed in Pr 15.20 would be the sum of the binary values shown in the table, i.e. 120.
Binary value for xx
1
2
4
8
16
32
64
128
15.21 to 15.23 Unused parameters
150
Parameter Keypad and
description format display
FI DE Txt VM DP ND RA NC
FI DE Txt VM DP ND RA NC
FI DE Txt VM DP ND RA NC
FI DE Txt VM DP ND RA NC
1
Digital I/O
Terminal T5
Terminal T6
Terminal T7
Terminals T8 & T9
www.controltechniques.com
CT Modbus User
RTU programming
NV PT US RW BU
1 1
NV PT US RW BU
1 1
NV PT US RW BU
1 1
NV PT US RW BU
1 1 1
Advanced parameter
CT Soft Menu 0
descriptions
PS
PS
PS
PS
Commander SK Advanced User Guide
Issue Number: 2
