Introduction Parameter x.00
description format
9.14

Logic function 2 source 1

Bit SP
Coding
Range Pr 0.01 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
This source parameter and Pr 9.04 define the inputs for source 1 of the programmable logic functions.
Only bit parameters can be programmed into these inputs.
If one or both inputs to the logic function are invalid, then the logic output will always be 0.
9.15

Logic function 2 source 1 invert

Bit SP
Coding
1
Range 0 or 1
Default 0
Update rate 21 ms
Setting this parameter and Pr 9.05 to a 1 causes the input sense of the logic functions to be inverted.
9.16

Logic function 2 source 2

Bit SP
Coding
Range Pr 0.01 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
This source parameter and Pr 9.06 defines the inputs for source 2 of the programmable logic functions.
Only bit parameters can be programmed into these inputs.
If one or both inputs to the logic function are invalid, then the logic output will always be 0.
9.17

Logic function 2 source 2 invert

Bit SP
Coding
1
Range 0 or 1
Default 0
Update rate 21 ms
Setting this parameter and Pr 9.07 to a 1 causes the input sense of the logic functions to be inverted.
9.18 Logic function 2 output invert
Bit SP
Coding
1
Range 0 or 1
Default 0
Update rate 21 ms
Setting this parameter and Pr 9.08 to a 1 causes the output sense from the logic functions to be inverted.
9.19 Logic function 2 delay
Bit SP
Coding
Range ±25.0 s
Default 0.0
Update rate 21 ms
If the delay parameter is positive, the delay ensures that the output does not become active until an active condition has been present at the input for
Commander SK Advanced User Guide
Issue Number: 2
Parameter Keypad and CT Modbus
display
FI DE Txt VM DP ND
2
FI DE Txt VM DP ND
FI DE Txt VM DP ND
2
FI DE Txt VM DP ND
FI DE Txt VM DP ND
FI DE Txt VM DP ND
1
www.controltechniques.com
User
CT Soft
RTU programming
RA NC NV PT US RW BU
1 1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
RA NC NV PT US RW BU
1 1
Advanced parameter
Menu 0
descriptions
PS
1
PS
PS
1
PS
PS
PS
Menu 9
