Menu 14 Introduction Parameter x.00
14.20

PID reference

Bit SP
Coding
Range ±100.0 %
Update rate 21 ms
This parameter monitors the reference input of the PID controller.
14.21

PID feedback

Bit SP
Coding
Range ±100.0 %
Update rate 21 ms
This parameter monitors the feedback input of the PID controller.
14.22

PID error

Bit SP
Coding
Range ±100.0 %
Update rate 21 ms
This parameter monitors the error of the PID controller.
144
Parameter Keypad and
description format display
FI DE Txt VM DP ND RA NC
1 1
FI DE Txt VM DP ND RA NC
1 1
FI DE Txt VM DP ND RA NC
1 1
www.controltechniques.com
CT Modbus User
RTU programming
NV PT US RW BU
1 1
NV PT US RW BU
1 1
NV PT US RW BU
1 1
Advanced parameter
CT Soft Menu 0
descriptions
PS
PS
PS
Commander SK Advanced User Guide
Issue Number: 2
