2: Device Layout

2.1 Exterior – Front
1. Pause Button
2. Delay Timer Button
3. Connector
4. Connector Holster
5. Halo Indicator
6. Closure Screws
7. Hinges
2.2 Exterior – LED Indicators
1. Pause
2. Charging
3. Power Available
4. Ready
5. Fault
6. Remote Control Activated
7. Service Portal
8. Time Delay
9. Hour Delay
10. Remote Control Lock
Note: Wi-fi and zigbee communication are not enabled for these versions.
9
1
6
3
3
4
©
7
1
2
7
5
10
6
5
2
4
8
9
813776
