Alarm Conditions

Alarm Conditions
Overview:
Screen Buttons:
Recognizing an Alarm
Condition:
The piezo can be silenced by pressing anywhere on the user interface touchscreen. Until the alarm conditions are
acknowledged, it will re-sound after 1 minute of inactivity at the user interface.
Piezo is emitting a pulsating tone
Figure 3. Alarm Condition Screen (Fire Alarm Shown as an Example)
An alarm condition occurs when an initiating device (such as a manual pull station,
smoke detector, etc.) activates. The panel indicates the presence of the alarm
condition by:
• Displaying messages on the user interface.
• Flashing the Fire
• Activating the building's notification appliances (horns and strobes).
Scroll Down
Scroll Up
When an alarm condition occurs, the following events occur at the user interface:
Fire
1. The Fire LED begins to blink
2. The piezo begins to sound a
pulsating tone
3. The user interface displays the
Fire Alarm in System screen,
which shows the list of all the
triggered alarms.
Note: A zone groups multiple points together, and the Zone Fire and Zone PRI2 Alarms lists dis-
play all the zones where alarm conditions occurred. You can view the points that triggered
the alarms within each zone by pressing on any given zone from the list.
Fire Alarm in System
First of 1
PULL STATION 1
FIRE ALARM
ACK
1
The Fire LED is blinking
The number displayed represents the number of alarms
5
4007ES Operator's Manual (579-1165)
or PRI2 LEDs.
Return
1. The PRI2 LED begins to blink
2. The piezo begins to sound a pulsating tone
3. The user interface displays the PRI2 Alarm in
System screen, which shows the list of all the
triggered alarms.
A list of alarms is displayed
Date
Time
Date
Alarm Functions Menu
Accept Decline
PRI2
