Simplex 4007ES Operator's Manual page 25

Diagnostics, Continued
Earth Fault Latch:
Earth Latch Menu
Off On ViewRaw
NAC Miswire Test:
NAC Test Menu
All Single
Duplicate Device Search:
Duplicate Dev Menu
Off On
Weak Answer Search:
Weak Answer Menu
Off On
Tap the Earth Fault Latch button to access the Earth Latch Menu
Date
Time
screen, which can be used to latch intermittent earth fault Troubles to
USER the panel. This allows the panel to consistently display a Trouble
BUTTON 1
instead of each time it re-occurs. The following functions are available:
USER
BUTTON 2
• Tap the Off button to disable the Earth Latch function.
USER
• Tap the On button to enable the Earth Latch function.
BUTTON 3
• Tap the ViewRaw button to view the locations of the raw earth
faults.
Tap the NAC Miswire Test button to access the NAC Test Menu
Date
Time
screen, which can be used to perform a wiring test on the Notifications
Appliance Circuits (NAC). The following functions are available:
USER
BUTTON 1
• Tap the All button to test all the NACs at once.
USER
BUTTON 2
• Tap the Single button to test each NAC separately.
USER
BUTTON 3
Tap the Duplicate Device Search button to access the Duplicate
Date
Time
Dev Menu screen, where On or Off buttons can be used to turn the
detection of duplicate devices on IDNet channels on or off.
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Tap the Weak Answer Search button to access the Weak Answer
Date
Menu screen, where the On or Off buttons can be used to turn the
Time
detection of weak answering devices on IDNet channels on or off.
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
25
4007ES Operator's Manual (579-1165)
Continued on next page
