Simplex 4007ES Operator's Manual page 27

Diagnostics, Continued
Install Mode:
Install Mode Menu
IViewMod IAddMiss IAddOpens
IRemvAll
NetDiag:
Net Diagnostics Menu
Network Diagnostics are not Active
This node is ONLINE
Network is Running in style 7
Diagnostics by Node
Net Diag Logging
Network Tallies
Diag Tbls Missing Node Troubles
Diagnostic Message options
Relay Mode
Repeater/Reset for all Nodes
Select
Current details of network
Item
Stop ALL Net Diag Functions
Install Mode is a feature that minimizes the number of Troubles
Date
Time
that occur when the system is being installed or is undergoing
USER
IRemvNorm extensive service, by placing points and cards that can cause
BUTTON 1
Troubles in Install Mode during those times. Install Mode raises a
USER
BUTTON 2
single "INSTALL MODE ACTIVE" Trouble, regardless of the number
USER
of items in it.
BUTTON 3
Tap the Install button to access the Install Mode Menu screen. The
following functions are available:
• Tap the IViewMod button to view all the items in Install Mode.
• Tap the IAddMiss button to add items to Install Mode.
• Tap the IAddOpens button to add all open circuits to Install
Mode.
• Tap the IRemvNorm button to remove an item from Install
Mode.
• Tap the IRemvAll button to remove all the items from Install
Mode.
Tap the NetDiag button to access the Net Diagnostics Menu screen,
Date
Time
where the following functions for analyzing and gathering network
information are available. Navigate to each option by using the
buttons. To select an option tap the Select Item button when it is
highlighted.
• Diagnostics by Node: Use this option to choose a node and
display its details.
• Net Diag Logging: Use this option to choose which network
parameters to log, and where these logs are saved.
• Network Tallies: Use this option to choose whether to view or
clear network tallies.
• Diag Tbls Missing Node Troubles: Use this option to enable or
disable missing node Troubles.
• Diagnostic Message Options: Use this option to select the
node to which diagnostic messages are sent, the message
directions, and the number of message retries.
• Relay Mode: Use this option to choose whether or not the
current node is in Relay Mode.
• Repeater/Reset for All Nodes: Use this option to reset/restore
nodes, or to put the nodes in Repeater Mode.
• Current Details of Network: Use this option to obtain
information on the number of nodes configured, communicating
and in Repeater Mode, as well as the Monitor node, Left End
node, Right End node, and the node's Repeater source. Use
this option to also determine the network topology, attendance,
and the node IDs.
• Stop ALL Net Diag Functions: Use this option to stop all the
network diagnostic functions that are currently running.
27
4007ES Operator's Manual (579-1165)
