Diagnostics, Continued
Piezo Silence:
Piezo Silence Menu
Off On
Cfig Download:
Configuration Menu
Enable Enable All Disable
Earth Fault Search:
Earth Fault Search?
Location IDNet LastResult
Tap the Piezo Silence button to access the Piezo Silence Menu
screen, where the On or Off buttons can be used to control the piezos
USER
at the panel and turn the Remote Annunciator's piezo on or off.
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Tap the Cfig Download button to access the Configuration Menu
Date
Time
screen. Inside, the following functions are available:
USER
1. Tap the Enable button to allow a job download to a remote panel.
Revert
BUTTON 1
2. Tap the Enable All button to allow a job download to all the remote
USER
BUTTON 2
panels.
USER
3. Tap the Disable button to disable the option of a job download to a
BUTTON 3
remote panel.
4. Tap the Revert button to access the following functions:
• Alt Cfig: Tap this button to see the details of the last job used by
the panel.
• Swap: Tap this button to swap the current job for the one used
by the panel last.
• NoSwap: Tap this button to move back to the Configuration
Menu screen.
Tap the Earth Fault Search button to access the Earth Fault
Date
Time
Search? screen, which can be used to test for earth faults in the
circuit. The following functions are available:
USER
BUTTON 1
• Press the Location button to display a list of cards that can be
USER
BUTTON 2
tested for earth faults.
USER
• Press the IDNet button to display a list of IDNet channels that
BUTTON 3
can be tested for earth faults.
• Press the LastResults button to view the results of the last
earth fault test.
