Supervisory and Trouble Conditions, Continued
Viewing the Supervisory and
Trouble Conditions Details:
1. Tap on a desired Trouble condition from the Trouble in System screen. That Trouble condition can either be a point
or a zone containing a variety of points. A point in Trouble state is shown as an example.
2. Take the necessary actions, using the buttons available at the point details screen. A Time and Date Trouble is used
as an example.
Each Supervisory or Trouble condition contains detailed information on the point (or
points) that have triggered it. To access that info (Trouble screen is shown as an
example):
Trouble in System
Most Recent of 5
SYSTEM TIME/DATE INVALID OR NOT SET
ABNORMAL
First of 5
CARD 1, NAC POWER SUPPLY
NAC MISWIRE TROUBLE
ACK
5
P58
SYSTEM TIME/DATE WAS NOT SET
On
Off
Time /Date
Auto
Trouble Details
12
4007ES Operator's Manual (579-1165)
Date
Time
Press to acknowledge
Press to acknowledge
Alarm Functions Menu
Date
Time
