Main Menu

Main Menu The Main Menu screen displays the functions available at the panel and can be accessed by:
Overview:
• Tapping anywhere on the touchscreen to remove the screensaver image.
• Tapping the Menu button on the user interface if the user interface is in use.
Screen Buttons:
User Button 1*
* User Buttons can be assigned to custom panel functions. Each function can be assigned to a
task, such as Manual evacuation or City Disconnect. User buttons that have not been assigned a
function do not appear on the user interface.
Main Menu Icons
System Info Use the System Info function to obtain detailed information regarding the panel and its
components.
Panel Setup Use the Panel Setup function to modify the configuration of the basic components.
Alarm Log The Alarm Log screen contains the list of alarms that the panel has received.
Trouble Log The Trouble Log screen contains the list of Troubles that the panel has received.
Search Use the Search screen to look for any configured point on the system controlled by the
panel.
System Reset Tap the System Reset button to reset all devices in alarm and clear all acknowledged
Alarms, Troubles and Supervisory conditions.
Tap the Hardware Reset button to re-initialize the state of certain hardware
Hardware Reset components. A hardware reset is typically used to reset Class A Troubles after the
problem causing the Trouble is resolved.
Diagnostics Use the Diagnostics function to run tests on the panel and the connected devices.
User Access Level Tap the User Access Level button to access the login screen. From this screen, the
user can log into the panel with a desired access level, or log out of the access level
that he is currently in.
Tap the Lamp Test button to light all 9 LEDs on the front panel for 5 seconds. The three
Lamp Test dual-colored LEDs blink alternately. The touch screen alternates between red, green
and blue.
Report Menu Tap the Report Menu button to generate various types of reports on the system points.
USER USER
BUTTON 1 BUTTON 2
User Button 2*
Main Menu
System Info Panel Setup
Search System Reset
User Access
Lamp Test
Level
Figure 4. Main Menu Screen
13
4007ES Operator's Manual (579-1165)
USER
BUTTON 3
User Button 3*
Alarm Log Trouble Log
Hardware
Diagnostics
Reset
Report Menu
Description
Return Button
Date
Time
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Page
16
18
20
21
22
8
22
23
14
13
27
