Report Menu

Report Menu Overview:
Screen Buttons:
Report Menu
AlarmLog
TrueAlert NAC
Verification Tally
Alarm Log:
Tap the AlarmLog button to generate a report containing the list of alarms that the panel has received.
Trouble Log:
Tap the TroubleLog button to generate a report containing the list of Troubles that the panel has received.
TrueAlarm Status:
Tap the TrueAlarm Status button to generate a report containing the status of the various TrueAlarm devices connected
to the panel. The report includes the following information:
• Device Number
• Custom Label
• Current Sensitivity of the Point
• Point Status: Normal, Trouble, Alarm
• Almost Dirty Status: Points that are almost dirty have an asterisk.
Press the Report Menu button to access the Report Menu screen, where various
types of reports on the system points can be generated. To generate a report:
1. Press the Report Menu button from the Main Menu screen to open the Report
Menu screen (Figure 13).
2. A report can either be saved to a USB key or printed. See instructions below for both
options:
Printing a Report
1. Press the Options button and then press
Select to choose a printer.
2. In the Report Menu screen, press a
report button to print the report.
Note: Pressing a report button without first inserting a USB key or choosing a printer generates
an error message stating that hardware could not be found.
Refer to Figure 6 for access levels required to use each option inside the Report Menu
screen.
Scroll Up
TroubleLog
TrueAlert Status TrueAlarm CO
Test
TrueAlert
Self-Test
Figure 13. Report Menu Screen
28
4007ES Operator's Manual (579-1165)
Saving a Report to a USB Key
1. Insert the USB key inside the USB
Port of the 4007ES CPU Card.
2. Press a report button to save the
report to the USB key.
Scroll Down
Return
TrueAlarm TrueAlarm
Status Service
Active List
Options
Date
Time
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Continued on next page
