2.2. General Specification

GENERAL SPECIFICATIONS
Power supply
maximum power
consumption
Isolation
ETHERNET
Ethernet
Protocol
Max connection length 100 m
Connection
RS485 COMMUNICATION PORTS
Number
Port #1
Port #2
Baudrate
Baudrate
ENVIRONMENTAL CONDITIONS
Temperature
Humidity
Storage temperature
BOX
Dimensions
Box; protection degree Black, PA6, IP20
CONNECTORS
STANDARDS
EN 61000-6-4/ 2007
EN 61000-6-2/ 2005
EN 61010-1/ 2001
USER MANUAL – Z-KEY
19.. 28 Vac (50..60 Hz), 11.. 40Vdc
1,2 W
1500 Vac
10 - 100 Mbit/s
Modbus TCP-IP
RJ 45 on frontal
2
IDC10 connector (Modbus RTU Master or slave port)
Screw terminals 10-11-12 (Modbus RTU Master or slave port)
1200..115200 configurable
1200..115200 configurable
-20 °C.. +50 °C
30 ..90% a 40 °C no condensing
-25..+85 °C
100 x 17,5 x 111 mm
IDC 10 for Seneca bus
Removable terminals, pitch 5,08 mm
Micro USB
Ethernet RJ45
Emission, industrial environmental
Immunity, industrial environmental
Safety
