USER MANUAL – Z-KEY

If you need to reset to the default parameters click on "FACTORY DEFAULT" button.

The parameters are explained below:

DHCP

Disable: A static Ip address is used

Enable: The IP address, the IP-Mask and the Gateway address are obtained from the DHCP server.

The Z-KEY IP address can be read from the USB port with the Easy Setup test configuration, or with the

Seneca Discovery utility (see the Z-KEY section on seneca web site for download).

STATIC IP ADDRESS

Static IP address when DHCP is Disable

STATIC IP MASK

mask when DHCP is Disable

STATIC GATEWAY

Gateway address when DHCP is Disable

WORKING MODE

Select the Modbus Gateway working mode with port 1 and port2 modbus slave.

RESPONSE MODE

Select which type of response do you want when a Modbus slave don't respond to a modbus request. You

can select from

Last value read (the value is freezed to the last value read)

Exception (Z-KEY exception response)

TCP/IP PORT

TCP-IP port for Modbus TCP-IP Server protocol (Max 8 clients)
