Accessing The Z-Key From Internet - Seneca Z-KEY User Manual

15.

ACCESSING THE Z-KEY FROM INTERNET

Using a static public ip address it's possible to configure the router for accessing Z-KEY from internet.
This operation it's known as "Virtual server "or "Port forwarding" refers to your Router documentation for
more info.
The Ip address of your internet connection must have a static public ip address, if your public ip address
isn't static you can obtain-it by using a Dynamic DNS like Dyndns (http://dyn.com/).
Take a look to this example:
The Router IP address is 192.168.1.1 and the Z-KEY device address is 192.168.1.101 with the Webserver on
port 80.
For example the Router Public IP address is 73.13.150.123.
Now we must open the port 80 on the router and forwarding it to the IP 192.168.90.101:
So the configuration on the router must be:
USER MANUAL – Z-KEY
IP ADDRESS PRIVATE PORT
192.168.1.101 80
PUBLIC PORT PROTOCOL
8080 UDP/TCP
89
