USER MANUAL – Z-KEY

DHCP

Disable: A static Ip address is used

Enable: The IP address, the IP-Mask and the Gateway address are obtained from the DHCP server.

The Z-KEY IP address can be read from the USB port with the Easy Setup test configuration, or with the

Seneca Discovery utility (see the Z-KEY section on seneca web site for download).

STATIC IP ADDRESS

Static IP address when DHCP is Disable

STATIC IP MASK

mask when DHCP is Disable

STATIC GATEWAY

Gateway address when DHCP is Disable

WORKING MODE

Select the Remote COM Port working mode, select which serial port to use (remember that only port #2

can be configured in RS232 mode).

TCP/IP PORT

TCP-IP port for Remote com port mode (default port 8000)

REMOTE COM PORT DELAY

Enter the silence time after which the serial packet is sent to the Ethernet. Can be that this value must be

adjusted for your specific application if you encounter communication errors.

PORT #n BAUDRATE
