PRELIMINARY WARNINGS

The word WARNING preceded by the symbol
The word ATTENTION preceded by the symbol
instrument or the connected equipment. The warranty shall become null and void in the event of improper use or
tampering with the module or devices supplied by the manufacturer as necessary for its correct operation, and if
the instructions contained in this manual are not followed.
WARNING: The full content of this manual must be read before any operation. The module must only be used by
qualified electricians. Specific documentation is available via QR-CODE shown on page 1.
Electrical and electronic waste disposal (applicable in the European Union and other countries with recycling).
The symbol on the product or its packaging shows the product must be surrendered to a collection centre
authorized to recycle electrical and electronic waste.
DOCUMENTATION
Z-KEY
SENECA s.r.l.; Via Austria, 26 – 35127 – PADOVA – ITALY; Tel. +39.049.8705359 - Fax +39.049.8706287
CONTACT INFORMATION
Technical support
This document is the property of SENECA srl. Copies and reproduction are prohibited unless authorised.
The content of this document corresponds to the described products and technologies.
Stated data may be modified or supplemented for technical and/or sales purposes.
MI00369-5-EN
INSTALLATION MANUAL
The module must be repaired and damaged parts replaced by the Manufacturer. The product is sensitive to
electrostatic discharges. Take appropriate measures during any operation.
support@seneca.it
INSTALLATION MANUAL
Z-KEY
Z-KEY-P
indicates conditions or actions that put the user's safety at risk.
indicates conditions or actions that might damage the
DOCUMENTATION
Z-KEY-P
Product information
sales@seneca.it
1/4
