The OTG Cable can be buy directly from
22.

CGI (common gateway interface) command

When Z-KEY is configured in Gateway mode it's possible to read tags values using CGI (Common Gateway
Interface) line commands.
The cgi syntax is (where 192.168.90.101 is the Z-KEY ip address and N is the TAG page to read):
http://192.168.90.101/index.cgi?page=N
N can be from 1 to 10, every page contain 50 tag values.
For example for obtain the first 50 tags the cgi can be:
http://192.168.90.101/index.cgi?page=1
the response is:
NAME: RTU name
FW: Firmware revision
DHCP: activated or not
IP: Actual IP address
NET: Network mask
GW: Gateway address.
MAC: MAC address.
MODE_NR:
USER MANUAL – Z-KEY
www.seneca.it
the actual mode:
0 = "MODBUS BRIDGE ON PORT#1"
1 ="MODBUS BRIDGE ON PORT#2",
and search for the "Seneca Easy Setup APP" icon
:
96
