19
Overview: Display modes
In the Program run, single block and Program run, full sequence
operating modes, as well as in Test Run operating mode, the
control displays the following soft keys:
Soft key
The position of the soft keys depends on the selected
operating mode.
The Test Run mode of operation also offers the following views:
Soft key
Limitations during program run
The simulation may contain errors if the control's
computing capacity is being fully utilized for complex
machining tasks.
806
View
Plan view
Projection in three planes
3-D view
View
Volume view
Volume view and tool paths
Tool paths
Test Run and Program Run | Graphics
HEIDENHAIN | TNC 640 | Conversational Programming User's Manual | 10/2017
