Caution: Danger to the tool and workpiece!
Use FUNCTION MODE TURN to select a kinematic model
prepared by the machine tool builder, which is necessary for
the use of facing slide. With this kinematic model, the controls
executes the programmed X-axis movements of the facing slide
as U-axis movements if the FACING HEAD function is active.
This automatism does not work if the FACING HEAD function
is inactive and in Manual operation mode, which means that
X-movements (programmed or axis key) are executed in the X
axis. In this case, the facing slide has to be moved with the U
axis. There is a danger of collision during retraction or manual
movements!
Position facing slide at home position with active
FACING HEAD POS function
Retract facing slide with active FACING HEAD POS function
In the Manual operation mode, move the facing slide with
the U axis key.
As the Tilt the working plane function is possible, pay
attention to the 3-D ROT status
