Displaying VLAN
Information
D
ISPLAYING
This chapter describes how to display information about VLANs to find
what VLAN indexes the Layer 3 Module has created for the 802.1Q
VLANs on which it is present.
The Layer 3 Module learns on which 802.1Q VLANs it is present from the
host switch. These VLANs are either statically configured, or learnt
through GVRP (GARP VLAN Registration Protocol). The module creates
corresponding VLAN indexes for all these VLANs automatically. The
module uses these VLAN indexes to assign IP addresses to VLANs.
You can display the VLANs that the module has learnt from the Switch
using the
bridge vlan summary
The summary includes the following fields:
Index — The system-assigned index number that identifies a VLAN.
VID — The VLAN ID, which is a unique, user-defined (12-bit) integer
that identifies this VLAN and is used by the global management
operations.
Name — The user-assigned name of the VLAN on the Switch.
To display a summary of VLAN information, enter the following at the
top-level menu:
bridge vlan summary
VLAN P
ARAMETERS
command.
