Removing the protective film from the storage shelf

Storage Shelf is heavier than the appliance. Therefore, you must install the storage
shelf in the bottom of the rack. Install the appliance above the storage shelves.
The following list describes dimensions of the storage shelf:
Height: 13.1 cm (5.25")
■
Width: 44.7 cm (17.6")
■
Depth: 56.1 cm (22.1")
■
Weight: 32.5 kg (71.7 lbs)
■
The rack rails that are provided for the Symantec Storage Shelf are extensible to
36" (914mm). This distance is the maximum depth that is allowed between rack
posts. If the distance between rack posts is longer than 36" (914mm) the rails and
the appliance cannot be properly installed. The width of the storage shelf is 19"
(482.6mm).
The appliance weight and dimensions are listed below.
52 pounds (23.58 kg)
■
27.39" (69.59 cm) deep
■
17.24" (43.8 cm) wide
■
3.45" (8.76 cm) high
■
The rack rails that are provided for the appliance are extensible to 30" (752mm).
This distance is the maximum depth that is allowed between rack posts. If the
distance between rack posts is longer than 30" (752mm) the rails and the appliance
cannot be properly installed. The width of the appliance is 19" (482.6mm).
Make sure that the installation location has extra space for the following:
Front bezels and rack handles
■
Rear panel power supply latches
■
Rear panel cable connectors
■
The Symantec Storage Shelf ships with a clear, protective film on the top, bottom,
and sides of the chassis. You need to remove the film before you install the storage
shelf into the rack. The storage shelf does not install properly if the film is not
removed.
The front panel and the rear panel do not include any film.
