Connecting the power cables

Do not bend the optical fiber into a circle with a radius less than 5 cm. Otherwise,
■
the optical fiber may be damaged, which reduces the system performance or
causes data loss.
To connect optical fibers
1 Put on proper ESD-preventive gloves or wrist straps.
2 Take the cap of the optical transceiver out of the interface of the tape out card
(two-port 8 Gb FC HBA).
3
Remove an optical fiber from its packaging.
4 Remove the caps of the optical connectors.
5 Plug an optical connector into the interface of the card.
6
Ensure that the optical connector is securely inserted into the optical transceiver.
7 Connect the other optical connector of the optical fiber to a Fibre Channel
switch.
See "About the cables"
Caution: The equipment should be completely installed and all network cables
should be connected before any devices are connected to power sources.
The NetBackup appliance has two power modules that are accessible on the rear
panel of the device. Each module requires a separate AC power cable or PDU cord.
Connect one end of the cable or cord to a power module, and then plug the other
end into a 120-VAC socket.
The storage shelf also has two power modules that are accessible on the rear panel
of the device. Each module requires a separate AC power cable or PDU cord.
Connect each module to a 120-VAC socket.
on page 39.
Cable connections
Connecting the power cables
43
