About hardware installation

Warning: NetBackup equipment and containers can weigh in excess of 70 lbs (31.75
kg). Improper handling can result in injury or equipment damage. Use appropriate
techniques, tools, and materials when handling NetBackup equipment.
The hardware installation flow is as follows:
Understand the NetBackup Appliance and the Symantec Storage Shelf.
■
Check safety precautions.
■
Check installation requirements.
■
The rack rails that are provided for the appliance are extensible to 31.5" (800mm).
The part number of these rails is AXXPRAIL. This distance is the maximum
depth that is allowed between rack posts. If the distance between rack posts is
longer than 31.5" (800mm) the rails and the appliance cannot be properly
installed. Other rails may have different lengths. The width of the appliance is
19" (482.6mm).
The rack rails that are provided for the Symantec Storage Shelf are extensible
to 36" (914mm). This distance is the maximum depth that is allowed between
rack posts. If the distance between rack posts is longer than 36" (914mm) the
rails and the appliance cannot be properly installed. The width of the storage
shelf is 19" (482.6mm).
Unpack the devices.
■
Install rack rails in the equipment racks for the NetBackup Appliance and
■
Symantec Storage Shelf. The storage shelf is heavier than the appliance. All
storage shelves should be installed at the bottom of the rack, below the
appliance.
Install the NetBackup Appliance and Symantec Storage Shelf into the rack rails.
■
The appliance height is 2U and the storage shelf height is 3U. Guide pins on
the devices are used to position the devices correctly on the rail. It sits completely
inside the rack.
Screws are provided with the hardware as needed. Insert the screws into the
■
rack. Use the screws in back and in front to secure the devices to the rack.
If your appliance rails have built-in pins instead of screws, secure the pins in
■
the rack holes. The blue pin indicates the bottom of the rail.
Connect the two SAS cables between the appliance and the Symantec Storage
■
Shelf that is closest to the appliance.
