Configuring the IPMI from the NetBackup Appliance
Shell Menu
Number Description
1 System ID button
2 NMI button (do not use)
3 eth0 NIC1 activity LED
4 eth2 NIC3 activity LED
5 System cold reset button
Check the power supply module LEDs on the rear panel. Each module has
■
one LED.
See "Hardware verification and turning on the NetBackup 5230 appliance and
storage shelf" on page 44.
This section explains how to configure IPMI from the NetBackup Appliance Shell
Menu.
Verifying the operation of the appliance and configuring IPMI

Configuring the IPMI from the NetBackup Appliance Shell Menu

Number
6
7
8
9
10
Description
System status LED
Power button and LED
Hard drive activity LED
eth3 NIC4 activity LED
eth1 NIC2 activity LED
48
