Appliance rear panel

Disk drive module LEDs (continued)
Table 1-2
Number Description
2 Activity LED
On the left side of the front panel, a black tag can be pulled out to display the serial
number of the appliance.
See "Appliance rear panel"
The NetBackup Appliance rear panel provides access to the communication ports,
PCIe add-in cards, and the hot-swappable power supplies. The add-in cards are
installed at the factory before the appliance ships.
Color
Not lit Solid green
Blinking green
Blinking green
occasionally
on page 12.
Introduction
Appliance rear panel
Indication
The disk has spun
down.
No disk activity.
The disk spins up.
Commands are
processed.
12
