Chapter 1 Introduction - Symantec NetBackup 5230 Installation Manual

Introduction
This chapter includes the following topics:
■
■
■
■
■
■
■
■
Product overview
Two disk drives in a RAID 1 configuration provide the operating system for the
appliance. These disk drives are located in slots 0 and 1 in the appliance front
panel.
The appliance also provides eight data and parity disk drives that vary in storage
capacity. These disk drives are located in slots 4 through 11 in the appliance front
panel. Refer to the Symantec NetBackup 5230 Appliance and Symantec Storage
Shelf Product Description for descriptions of the storage capacities that are available.
Configurations that include at least one Storage Shelf require a SAS RAID controller
card that is installed in a PCIe add-in slot in the appliance. The appliance also has
the Fibre Channel port cards that are installed in the PCIe slots for all configurations.
Product overview
Appliance front panel
Appliance rear panel
PCIe riser assemblies and slot numbers
Storage shelf front panel
Storage shelf rear panel
About IPMI configuration
Product documentation
