Storage shelf rear panel

Symantec Storage Shelf system LED status indicators (2)
Table 1-5
LED name State
Power Not lit
Solid green
Global enclosure Not lit
status
Solid green
Amber
Red
Reserved N/A
I/O Module 1 activity Not lit
Flashes green
I/O Module 2 activity Not lit
Flashes green
Heartbeat Not lit
Flashes green
The 16 disk drives in the storage shelf are labeled as shown. The drive in slot 16
is the hot spare.
See "Storage shelf rear panel"
The rear panel of the Symantec Storage Shelf contains two I/O modules and two
power supplies. The I/O modules make the storage capacity in the storage shelf
available to the RAID controller in the NetBackup Appliance. This section provides
information about the rear panel of the storage shelf.
Description
Off
On
Off
On
One power supply offline
Both power supplies offline
N/A
No activity
Activity
No activity
Activity
System off
Normal operation
on page 15.
Introduction
Storage shelf rear panel
