Trianco EuroTrader 50/90 User, Installation, Commissioning & Servicing Instructions page 20

14
15
13
12
11
10
Fig. 9
2273 UNIVERSAL VERTICAL
BALANCED FLUE KIT
6
16
17
7
8
9
20
Item Description
1 Apron Cravat
2 Vertical terminal silencer
3 Clamping strap
4 M4 x 35 Pan head Pozi
5 No. 8 Self tapping screw
6 Silicone sponge
7 Ceiling plate half
{
Flue socket plate
(supplied with boiler)
8
Flue socket plate
(WH70 only)
9 Gasket
(supplied with boiler)
10 Inner pipe bottom lower section
11 M6 nuts & washers
12 Jubilee clip
13 Outer flue pipe with hose connection
14 Inner pipe lower section
15 Outer pipe lower section
16 Inner pipe middle section
17 Outer pipe middle section
18 Inner pipe top section
19 Outer pipe top section
20 Flue infill plate
- Inner 'O' ring
- Outer 'O' ring
17
5
2
3
18
4
19
Part no. No. Off
221674
221672
221673
-
-
98112
208583
207772
221648
204072
221668
-
95256
221662
221726
221725
221669
221665
221670
221667
209597
221647
221666
1
1
1
1
4
4
2
pcs
2
1
1
1
1
4
2
1
1
1
1
1
1
1
4
4
