  • Page 1 TRIANCO FS PREMIER EXTERNAL 50/90 FS PREMIER EXTERNAL 100/125 CONDENSING BOILER OIL FIRED CENTRAL HEATING BOILERS FOR BALANCED OR CONVENTIONAL FLUE BED 92/42 EEC EMC 89/336 EEC USER, INSTALLATION COMMISSIONING & SERVICING INSTRUCTIONS To be retained by householder...
  • Page 2 HEALTH AND SAFETY INFORMATION FOR THE INSTALLER AND SERVICE ENGINEERS Under the Consumer Protection Act 1987 and the Health and Safety at Work Act 1974, it is a requirement to provide information on substances hazardous to health (COSHH Regulations 1988). The Company takes every reasonable care to ensure that these products are designed and constructed to meet these general safety requirements, when properly used and installed.
  • Page 3: Table Of Contents

    CONTENTS PAGE 1. USER INSTRUCTIONS Introduction How to use the boiler After-sales service information 2. INTRODUCTION TO INSTALLATION 3. TECHNICAL INFORMATION Technical specifications 4. INSTALLATION Regulations / Health and Safety Siting System design Ventilation Heating & hot water systems Electrical supply Wiring diagram Condensate drain connections 5.
  • Page 4: User Instructions

    1. USER INSTRUCTIONS BOILER CONTROL THERMOSTAT The boiler control thermostat allows you to select the Please note, to assist Trianco in improving customer temperature of the water leaving the boiler. It is calibrated service, it is important that the guarantee/registration between High and Low, in five intermediate settings, card is returned.
  • Page 5 SYSTEMS CONTROLS ROOM THERMOSTAT SIMPLE FAULT FINDING The room thermostat should not be positioned near a If the boiler fails to start for no apparent reason, carry source of heat, such as a radiator, or be exposed to direct out the following checks before calling your service sunlight, as this will cause the central heating to switch off engineer.
  • Page 6: After-Sales Service Information

    What happens if my installer/engineer is oil), or with equipment not supplied by Trianco. unavailable? Step 3: Contact Trianco Direct. We will provide you with • the name and telephone number of our Where the appliance falls outside the guarantee Service Agent.
  • Page 7: Introduction To Installation

    INSTALLATION INSTRUCTIONS 2. INTRODUCTION The Trianco Eurostar External Premier condensing boiler The boiler is fully automatic in operation and incorporates been designed conform European all necessary safety controls to ensure safe and reliable Directive/Standards BED 92/42 EEC LVD 73/23/EEC EMC running.
  • Page 8: Technical Information

    3. TECHNICAL INFORMATION ALL DIMENSIONS IN mm. 50/90 100/125 1005 1038 ALL UNUSED TAPPINGS ARE TO BE PLUGGED OFF 807.5 1040 603.5 73.5 73.5 133.5 130.5 649.5 702.5 746.5 161.5 870.5 865.5 Fig. 3 OUTLINE DIMENSIONS Fig. 4 PIPEWORK CONNECTIONS...
  • Page 9: Technical Specifications

    TECHNICAL SPECIFICATION Boiler Models 50/90 100/125 Weight (empty) Water Content litres 22mm Compression Flow & Return Connections Supplied With Boiler Flue Max. Operating Pressure 43.5 Test Pressure 65.3 Water Side Resistance 10 diff mbar 25.4 20 diff mbar Starting Current Running Current 0.77 Control Thermostat...
  • Page 10: Installation

    4. INSTALLATION REGULATIONS Clearance and Service Access When siting the boiler, ensure adequate clearance is Installation of the boiler must comply with the following allowed for making water and flue connections. As the British Standards and Regulations: boiler can be fully serviced from the front, there is no need for headroom.
  • Page 11: Electrical Supply

    ELECTRICAL SUPPLY 230V 1 Phase 50Hz (fused 5 Amp) The minimum requirement for the power supply cable is PVC sheathed flexible cord, 0.75mm (24x0.2mm, code Note: this appliance must be earthed and the electrical designation H05 VV-F or H05 VVH2-F), as specified in supply cable must be of a greater length than table 16 of BS 6500.
  • Page 12: Condensate Drain Connections

    CONDENSATE DRAIN CONNECTIONS If the boiler is to be fitted in a position where the drain The condensate trap can be run to either the left or the level is higher than the boiler, a condensate pump can be right side of the boiler. fitted (refer to manufacturers’...
  • Page 13: Oil Supply

    BS 2869. 1.8m from the top of the tank. Trianco makes no guarantee as to the satisfactory Cladding must extend at least 300mm beyond the operation of the boiler using fuels other than which is tank.
  • Page 14: Single Pipe Oil Supply

    An additional flexible hose is also required. the ‘U’ washer must be removed in the same manner as a standard two-pipe system. 50 mm (2'') DIA AIR VENT REFER TO MANUFACTURERS INSTRUCTIONS FOR ‘OIL DE-AERATOR’ INSTALLATION DETAILS TRIANCO EUROSTAR FIRE VALVE TERMINAL BOILER SENSOR OIL DE-AERATOR...
  • Page 15: Single Pipe Oil Supply

    PIPE 6mm ID LENGTH PIPE 8mm ID (METRES) 2'' BSP MALE 50mm(2'') DIA HOSE CONNECTION AIR VENT WITH CAP LEVEL GAUGE TRIANCO FIRE VALVE SENSOR EUROSTAR BOILER GUARD STEEL TERMINAL OIL STORAGE TANK LEVEL GAUGE ISOLATING VALVE VALVE 25mm (1'')
  • Page 16: Flue Discharge

    A distance of at least 600mm must be allowed between a) Trianco condensing boilers operate at high efficiencies the terminal and any window, door or other opening with low flue gas temperatures. The flue system used into the building (see fig.
  • Page 17: Assembly

    FLUE ASSEMBLY The flue terminal pack (supplied) should contain the 3) Smear a thin bead of silicone sealant (supplied) following items. Check all components are present around the ‘o’-ring seal and slide the terminal into before fitting: the elbow from the outside of the boiler casing, being careful to ensure that the ‘o’-ring remains in 1 x Flue Terminal Assembly place.
  • Page 18: Commissioning

    7. COMMISSIONING 8. SERVICING The boiler/burner MUST be commissioned by a qualified IMPORTANT: ISOLATE ELECTRICAL SUPPLY TO THE OFTEC-Registered technician, and a CD/10 form BOILER BEFORE SERVICING completed. To maintain the boiler’s high thermal efficiency and It is the responsibility of the installer to ensure the boiler reliable operation, it should be serviced annually by a is properly commissioned, failure to do so will make the qualified and registered OFTEC engineer.
  • Page 19: Baffle Configuration

    Servicing the Boiler 1 Remove the flexible air supply hose. 10 Check to ensure that the condense drain is working and not blocked by pouring a small amount of water 2 Remove burner ensure that if flexible oil supply hose into condenser unit and checking to see that water has to be disconnected that there is no spillage of oil.
  • Page 20: Fault Finding

    9. FAULT FINDING ELECTRICITY SAFETY - Before making any electrical checks, switch off mains supply to boiler. FAULT POSSIBLE CAUSE ACTION BURNER WILL NOT START Control box locked out Press reset button on front of burner. N.B. ONLY TRY TWICE Limit-stat tripped Press reset button under control panel and check function of boiler control thermostat.
  • Page 21: Fault Finding

    FAULT FINDING (Cont’d) FAULT POSSIBLE CAUSE ACTION MORNING START LOCK-OUT Faulty non-return valve or air leak Replace non-return valve and cure leak. in two pipe system Low voltage Check with local Electricity Board. Combustion readings incorrect Check combustion under normal running conditions and compare readings with those given under ‘Burner Settings’.
  • Page 22: Spares

    SPARES Item Description 50/90 100/125 Boiler Body 223460 223464 Right Panel 223496 223506 Left Panel 223495 223505 Top Panel 210952 221712 Front Door 223493 223503 Back Panel 223497 223507 Condensing Unit Clamp 223133 223133 Control Box 210799 210799 Boiler Thermostat 206896 206896 High-Limit Thermostat...
  • Page 23: Boiler Assembly Drawing

    FIG. 14 BOILER ASSEMBLY...
  • Page 24 Fax: (0114) 245 1419 www.trianco.co.uk © Trianco Limited, Copyright in this brochure and the drawings or illustrations contained in it is vested in Trianco Limited and neither the brochure or any part thereof may be reproduced without prior written consent.
