EuroTrader 50/90
BAFFLE ARRANGEMENT
FLUE GAS
SAMPLING POINT
FLUE
COVER
BAFFLES MUST BE FITTED IN
THE ARRANGEMENT SHOWN
i.e. GAP ALTERNATING FROM
BACK TO FRONT
PART NO.
208838
3-OFF
PART NO.
208834
1-OFF
FIG. 12 BAFFLE DETAILS
20
PART NO.
208865
2-OFF
PART NO.
208871
6-OFF
EuroTrader 125
BAFFLE ARRANGEMENT
