Trianco EuroStar WM 50 User, Installation, Commissioning & Servicing Instructions
Oil fired central heating boilers. internal wall mounted 50/70
Hide thumbs
Also See for EuroStar WM 50:
Subscribe to Our Youtube Channel
Related Manuals for Trianco EuroStar WM 50
Summary of Contents for Trianco EuroStar WM 50
- Page 1 TRIANCO BALANCED FLUE OIL FIRED CENTRAL HEATING BOILERS BED 92/42 EEC EMC 89/336 EEC USER, INSTALLATION COMMISSIONING & SERVICING INSTRUCTIONS Internal Wall Mounted 50/70 To be retained by householder...
- Page 2 HEALTH AND SAFETY INFORMATION FOR THE INSTALLER AND SERVICE ENGINEERS Under the Consumer Protection Act 1987 and the Health and Safety at Work Act 1974, it is a requirement to provide information on substances hazardous to health (COSHH Regulations 1988). The Company takes every reasonable care to ensure that these products are designed and con- structed to meet these general safety requirements, when properly used and installed.
-
Page 3: Table Of Contents
CONTENTS PAGE 1. USER INSTRUCTIONS After sales service information 2. INTRODUCTION Technical Specification 3. INSTALLATION Regulations Siting the Boiler Wall Fixing and Outline Dimensions Ventilation Electrical Supply 4. OIL SUPPLY Storage Tank - Steel and Plastic Oil supply line Oil De-aerator - Single pipe supply 5. -
Page 4: User Instructions
High and Low in five intermediate settings, corresponding to a temperature range of 82°C The Trianco EuroStar WM has been designed and con- (high) to 60°C (low). structed to give you years of trouble free service and... - Page 5 SYSTEMS CONTROLS Sludge and water caused by condensation should be drawn off at the tank drain-cock annually. ROOM THERMOSTAT SIMPLE FAULT FINDING The room thermostat should not be positioned near a If the burner fails to start for no apparent reason, make source of heat such as a radiator or exposed to the sun the following checks before calling your Service as this will cause the central heating to switch off before...
-
Page 6: After Sales Service Information
What happens if my installer/engineer is unavailable? • Step 3: Contact Trianco Direct. We will provide you with Where the appliance falls outside the 12 month the name and telephone number of our Service guarantee period (see terms and conditions enclosed). -
Page 7: Introduction
2. INTRODUCTION IMPORTANT SAFETY NOTES The Trianco EuroStar Wall Mounted boiler is designed to Read these instructions before installing your boiler. operate with high efficiency and clean combustion on open vent fully pumped systems and sealed systems. The heating system must comply with the latest editions... -
Page 8: Technical Specification
Technical Specification EuroStar Boiler Model WM 50/70 Rated Input (Btu/h) 77,800 (kW) 22.8 Rated Output (Btu/h) 70,000 (kW) 20.5 Oil Burner Model See Burner Details Leaflet Weight (empty) (kg) Water content (litre) 14.5 Flow and return sockets (mm) 22mm Compression Flue Gas Temp. -
Page 9: Installation
3. INSTALLATION (b) Small rooms tend to amplify noise, particularly if the wall construction is hollow or the surface tiled. Regulations (c) A chimney passing through a bedroom can some times transmit noise. Installation of the boiler must comply with the following British Standards and Regulations: (d) Low level flue terminals produce some exhaust noise, so care should be taken when siting adjacent... -
Page 10: Wall Fixing And Outline Dimensions
Fixing Casing to the Boiler IMPORTANT Before securing casings in position, ensure squareness (a) With the boiler in position, fit casing support bracket to and alignment of door casing. the wall mounting bracket (see fig. 2/3). (b) Casing support bracket can be adjusted using the 2 Water System fixing screws. -
Page 11: Ventilation
Ventilation This appliance MUST be earthed and the electrical supply earth cable must be of a greater length than the Although no openings are required for the supply of current carrying conductor cables (ie live and neutral combustion air (this comes from outside through the air supply cables). -
Page 12: Oil Supply Line
Alternatively, a non-combustible radiation barrier must be All oil line joints must be completely sealed and the total provided which meets the requirements of BS 5410 pipe run thoroughly flushed out before connecting to the Part 1: This standard applies to tanks up to a capacity of burner. - Page 13 FIG. 6 SINGLE PIPE OIL SUPPLY INSTALLATION...
- Page 14 FIG. 7 TWO PIPE OIL SUPPLY INSTALLATION...
- Page 15 FIG. 8 DE-AERATED OIL SUPPLY INSTALLATION...
-
Page 16: Balanced Flue System
Whereas some balanced flue boilers rely on case sealing Only Kerosene 28 sec. Class C2 is permitted for to achieve a room seal, Trianco boilers have a sealed air boilers using low level flue discharge. duct system which maintains the room sealed... -
Page 17: 600Mm/1000Mm Horizontal Bf Installation
91601 No. 6x12mm STS Pozi. HD 91523 Trianco flue kits are designed to incorporate the latest ‘O’-ring seals. Before commencing assembly, please make sure that all ‘O’-rings seals are in position. 600mm HORIZONTAL TELESCOPIC BF KIT 1000mm HORIZONTAL TELESCOPIC BF KIT... - Page 18 2270 600mm Horizontal Telescopic BF Kit 2271 1000mm Horizontal Telescopic BF Kit Fig. 11...
-
Page 19: High Level Adaptor Kit
2272 High Level Adaptor Kit used in conjunction with 2270 or 2271 (dimension ‘A’) (dimension ‘A’) KIT 2270 KIT 2270 (10'') 225mm MIN (4'') 100mm MIN (21'') 530mm MAX (15'') 380mm MAX KIT 2271 KIT 2271 (22'') 560mm MIN (19'') 495mm MIN (36'') 930mm MAX (38'') 780mm MAX REAR OUTLET... - Page 20 Note: Supplied with the kit are two spigots. Use the ASSEMBLY METHOD WITH 1000mm KIT ( Fig. 12 ) spigot that does not have chamfered corners. The other spigot is not required for this installation. 1. Fix boiler mounting template into position. Having decided the position of the boiler cut a hole in the wall 9.
-
Page 21: Vertical Bf Kit
Vertical Balanced Flue Kit The vertical balanced flue kit is designed to be telescopic in nature and incorporates the latest ‘O’ ring seals. It is therefore unnecessary for any ‘cutting down’ of pieces to the required size. Please note that to facilitate the connection process, each section of pipe has a different diameter. The lowermost pipes have the smallest diameter, the size increasing with each subsequent section of pipe. - Page 22 Fig. 13...
-
Page 23: Electrical
6. ELECTRICAL Control Box Installation Electricity Supply 230V, Single Phase 50Hz All wiring to supply and all system components external to the boiler must comply with the latest edition BS 7671 IEE Wiring Regulations. Fig. 14... -
Page 24: Commissioning
All instructions should be handed to the user for retention and advice regarding the need for annual servicing. The guarantee form should be completed and returned to Trianco. -
Page 25: Fault Finding
9. FAULT FINDING ELECTRICITY SAFETY - Before making any electrical checks, switch off mains supply to boiler. FAULT POSSIBLE CAUSE ACTION BURNER FAILS TO START Control box locked out - Light on Press control box reset button. N.B. ONLY TRY TWICE Boiler overheat thermostat or Ensure all controls are calling for heat and other system controls satisfied... -
Page 26: Fault Finding
FAULT FINDING (Cont’d) FAULT POSSIBLE CAUSE ACTION POOR FLAME CUT-OFF Air in pump or at back of nozzle Bleed pump through pressure gauge port, also check for leaks in oil line if 2-pipe system. Oil contaminated with water Run off oil at burner until free of water and drain condensation from tank. -
Page 27: Spares
10. SPARES FIG. 15... -
Page 28: Boiler Parts
EuroStar W.M. Boiler Parts Item Description Part Code Boiler Body 208311 Air Box 208370 Air Hose 208388 Burner Assembly 221320 Cleaning Cover 208331 Baffle Set 208320 Bottom Baffle 208324 Brass Nut 99369 Olive (22mm Compression ring) 99370 Flexible Oil Line 207019 Wall Mounting Bracket Assembly 208327... - Page 32 Fax: (0114) 257 1419 www.trianco.co.uk © Trianco Limited, Copyright in this brochure and the drawings or illustrations contained in it is vested in Trianco Limited and neither the brochure or any part thereof may be reproduced without prior written consent.
