Summary of Contents for Trianco EuroStar 50-90

  • Page 1 TRIANCO FLOOR STANDING OIL FIRED CENTRAL HEATING BOILERS FOR EXTERNAL INSTALLATION ONLY BED 92/42 EEC EMC 89/336 EEC USER, INSTALLATION COMMISSIONING & SERVICING INSTRUCTIONS FS External Models EuroStar 50-90 EuroStar 95-115 To be retained by householder...
  • Page 2 HEALTH AND SAFETY INFORMATION FOR THE INSTALLER AND SERVICE ENGINEERS Under the Consumer Protection Act 1987 and the Health and Safety at Work Act 1974, it is a requirement to provide information on substances hazardous to health (COSHH Regulations 1988). The Company takes every reasonable care to ensure that these products are designed and con- structed to meet these general safety requirements, when properly used and installed.
  • Page 3: Table Of Contents

    CONTENTS PAGE 1. USER INSTRUCTIONS After sales service information 2. INTRODUCTION 3. TECHNICAL INFORMATION Outline Dimensions Technical specifications External model wiring diagram 4. INSTALLATION Regulations Health and Safety Siting the Boiler Heating and domestic hot water system Electrical supply Thermostats Frost Protection 5.
  • Page 4: User Instructions

    It is calibrated between High and Low in five intermediate settings, The Trianco EuroStar has been designed and corresponding to a temperature range of 82°C (high) to constructed to give years of trouble free service and 55°C (low).
  • Page 5: Simple Fault Finding

    SYSTEMS CONTROLS SIMPLE FAULT FINDING If the burner fails to start for no apparent reason, make ROOM THERMOSTAT the following checks before calling your Service Engineer. The room thermostat should not be positioned near a source of heat such as a radiator or exposed to the sun Check for failure in the electrical supply e.g.
  • Page 6: After Sales Service Information

    What happens if my installer/engineer is oil), or with equipment not supplied by Trianco. unavailable? Step 3: Contact Trianco Direct. We will provide you with • the name and telephone number of our Where the appliance falls outside the guarantee Service Agent.
  • Page 7: Introduction

    NO x emissions operation. The EuroStar boilers are suitable for all normal open Trianco EuroStar boilers are supplied with the burner set vented central heating and indirect hot water systems but for Kerosene 28 sec. Class C fuel to meet the Building can also be used with sealed systems up to a working Regulation requirements for low level flue discharge.
  • Page 8: Technical Information

    3. TECHNICAL INFORMATION NOTE: ALL DIMENSIONS IN MM MODEL 50/90 1015 95/115 1075 MODEL 50/90 95/115 FLOW & RETURN SOCKET SIZES MODEL 50/90 95/115 1 1/4'' FLOW RETURN PIPE ACCESS POINTS SIDE VIEW FLOW & RETURN PIPE LOCATIONS Boiler Tapping Positions OIL LINE ENTRY...
  • Page 9: Technical Specifications

    Technical Specification EuroStar Boiler Models 50/90 95/115 Rated Input (Btu/h) 98,000 127,700 (kW) 28.6 37.4 Rated Output (Btu/h) 90,000 115,000 (kW) 26.4 33.7 See Burner See Burner Burner Details Leaflet Details Leaflet Weight (empty) (kg) Water content (litre) Flow & return sockets (in.) 4 x 1 BSP 4 x 1 1/4 BSP...
  • Page 11: Installation

    4. INSTALLATION Combustion Air (Conventional flue boilers) The provision of an adequate supply of combustion air is Regulations essential for the efficient and safe operation of the boiler. The combustion air inlet is located at the top of the front Installation of the boiler must comply with the following panel which under no circumstances should be covered British Standards and Regulations:...
  • Page 12: Electrical Supply

    Electrical Supply Warning - High and Low Voltage 230V 1 Phase 50Hz (Fused 5 Amp) In certain parts of the country, where there is a known risk of high or low voltage fluctuations, the oil burner shall be Note: THIS APPLIANCE MUST BE EARTHED prevented from starting by the use of a voltage sensitive device if the voltage drops or increases sufficiently to All electrical wiring must be carried out by a qualified...
  • Page 13: Oil Supply Line

    Steel Tanks Fire Valve Steel tanks should comply with the requirements BS 799, Pt. 5: 1987 and mounted on brick or block piers with a A fire-valve must be fitted in the oil line outside the waterproof membrane between the piers and tank. building with its sensing phial positioned within the boiler casing below the control panel.
  • Page 14 PIPE 6mm ID LENGTH PIPE 8mm ID (METRES) 2'' BSP MALE 50mm(2'') DIA HOSE CONNECTION AIR VENT WITH CAP LEVEL GAUGE TRIANCO FIRE VALVE SENSOR EUROSTAR BOILER GUARD STEEL TERMINAL OIL STORAGE TANK LEVEL GAUGE ISOLATING VALVE VALVE 25mm (1'')
  • Page 15 FIG. 6 DE-AERATED OIL SUPPLY INSTALLATION...
  • Page 16: Flue System

    To evacuate the products of combustion safely and thor- recommended terminal positions). oughly, the boiler must have an efficient flue system. The design and construction of the Trianco Flue already takes Flue Sealing these factors into account . As the flue system operates under positive pressure, it is essential to seal all flue joints.
  • Page 17: Terminal Assembly

    FITTING THE FLUE TERMINAL 1 With the back panel (item 1) removed for connecting the pipework, place the gasket (item 3) up to the acoustic box (item 2) using the M6 studs for location. 2 Fit the back panel (item 1) in position and secure with the 9xM5 screws provided 3 Place the second gasket (item 4) up to the back panel 4 Fit the terminal box (item 5) with the discharge pointing downwards and secure with the 4xM6 nuts.
  • Page 18: Commissioning

    8. SERVICING 7. COMMISSIONING IMPORTANT: ISOLATE ELECTRICAL SUPPLY TO THE It is strongly recommended that the boiler/burner unit is BOILER BEFORE SERVICING commissioned by a qualified technician, preferably OFTEC trained and registered. To maintain the boiler’s high thermal efficiency and reliable operation, it should be serviced annually by a It is the responsibility of the installer to ensure the boiler qualified engineer preferably OFTEC trained and...
  • Page 19: Burner

    Servicing the Boiler Replace flue-baffles in the correct arrangement (See Fig. 9 for order of assembly). Refit the flue- (Burner removed) cover and fully tighten wing-nuts to make a gas tight seal. Remove flue-cover and lift out flue-baffles (See Fig. 9). Refit burner to boiler, connect flexible air hose and plug-in burner lead.
  • Page 20: Fault Finding

    9. FAULT FINDING ELECTRICITY SAFETY - Before making any electrical checks, switch off mains supply to boiler. FAULT POSSIBLE CAUSE ACTION BURNER WILL NOT START Control box locked out Press reset button on front of burner. N.B. ONLY TRY TWICE Limit-stat tripped Press reset button under control panel and check function of boiler control thermostat.
  • Page 21: Fault Finding

    FAULT FINDING (Cont’d) FAULT POSSIBLE CAUSE ACTION POOR FLAME CUT-OFF Air in pump or at back of nozzle Bleed pump through pressure gauge port, also check for leaks in oil line if 2-pipe system. Oil contaminated with water Run off oil at burner until free of water and drain condensation from tank.
  • Page 22: Spares

    EuroStar Boiler Parts Description No. Off 50/90 95/115 Boiler Body 222420 222430 R/H Side Panel Assembly 210801 210781 L/H Side Panel Assembly 210800 21780 Top Panel Assembly 210806 210782 Back Panel 210808 210784 Boiler Control Thermostat 206896 206896 Limit Thermostat 206892 206892 Gasket...
  • Page 23 Fax: (0114) 257 1419 www.trianco.co.uk © Trianco Limited, Copyright in this brochure and the drawings or illustrations contained in it is vested in Trianco Limited and neither the brochure or any part thereof may be reproduced without prior written consent.
