View line configuration
External analogue readings
View menu example
MAINS FAILURE
U-supply 24.1 V
G 0.001 PF 0 kW
G 0 kVA 0 kVAr
AGC 200
2010-01-06 08:59:08
Press
MAINS FAILURE
P 0 kW 0 %
Q 0 kVAr 0 %
S 0 kVA 0 %
AGC 200
2010-01-06 08:59:08

4.1.8 Mode overview

The unit has four different running modes and one block mode. The modes are selected directly with push-
buttons in the lower right corner of the unit front.
Auto
In auto mode, the unit will operate automatically and the operator cannot initiate any sequences manually.
Semi-auto
In semi-auto mode, the operator must initiate all sequences. This can be done via the push-button functions,
Modbus commands or digital inputs. When started in semi-automatic mode, the genset will run at nominal
values.
Test
The test sequence will start when the test mode is selected.
Manual
When manual mode is selected, the binary increase/decrease inputs can be used (if they have been config-
ured) as well as the start and stop push-buttons. When starting in manual mode, the genset will start without
any subsequent regulation.
DEIF A/S
MAINS FAILURE
Event log
Press
Alarm log
Battery test log
Press
MAINS FAILURE
MAINS FAILURE
Wed Jan 06 13:36:23
MB OFF
Wed Jan 06 13:36:23
The scrollbar
indicates that more
readings are
available below
Display and menu structure
MAINS FAILURE
Setup menu
Press
1000 Protection
2000 Synchronisation
2500 Regulation
3000 Binary input
Press
MAINS FAILURE
Setup menu
1000 G -P>
1010 G -P>
1030 G I>
1040 G I>
Press
MAINS FAILURE
1010 G -P>
Setpoint : -9.0 %
Timer : 10.2 s
Output A : Not used
Output B : Not used
1
2
1
2
1
