4.1.6 Texts only related to power management (AGC 24x only)

Status text
BLACKOUT ENABLE
UNIT STANDBY
DELOADING BTB XX
BTB XX DIVIDING SEC.
SYNCHRONISING TB XX
SYNCHRONISING MB XX
SYNCHRONISING BTB XX
Deloading TB XX
UNIT STANDBY
TB TRIP EXTERNALLY
DIVIDING SECTION
READY AUTO OPERATION
SEMI-AUTO OPERATION
AUTO OPERATION
BLOCKED FOR CLOSING
BTB TRIP EXTERNALLY
BROADCASTING APPL. #
DEIF A/S
Condition
DG unit
This info is shown if a CAN failure is present in a pow-
er management application.
If redundant mains units are present, this message is
shown on the redundant unit.
DG units are load sharing asymmetrically to deload
BTB XX dividing two sections in an island application.
BTB XX is dividing two sections in an island applica-
tion.
TB XX is synchronising.
MB XX is synchronising.
BTB XX is synchronising.
Displays that a tie breaker is being deloaded in semi-
auto mode.
Mains unit
If redundant mains units are present this message is
shown on the redundant unit.
Some external equipment has tripped the breaker.
BTB unit
A BTB unit is dividing two sections in an island appli-
cation.
BTB unit in Auto and ready for breaker operation (no
active BTB trip" alarm).
BTB unit in Semi-auto
BTB unit in Auto, but not ready for breaker operation
(active "BTB trip" alarm).
Last open BTB in a ring bus.
Some external equipment has tripped the breaker.
All units
Broadcast of an application through the CAN line.
Display and menu structure
Comment
An external trip is
logged in the
event log.
An external trip is
logged in the
event log.
Broadcasts one of
the four applica-
tions from one unit
to the other AGCs
in the power man-
agement system.
