4.1.7 Available display views

View line configuration
For generator
G f-L1 frequency L1 (Hz)
G f-L2 frequency L2 (Hz)
G f-L3 frequency L3 (Hz)
Gen. active power (kW)
Gen. reactive power (kVAr)
Gen. apparent power (kVA)
Power factor
Voltage angle between L1-L2 (deg.)
Voltage angle between L2-L3 (deg.)
Voltage angle between L3-L1 (deg.)
BB U-L1N
BB U-L2N
BB U-L3N
BB U-L1L2
BB U-L2L3
BB U-L3L1
BB U-MAX
BB U-Min
BB f-L1
BB AngL1L2-180.0deg
BB-G Ang -180.0deg
U-Supply (power supply V DC)
Energy counter, total (kWh)
Energy counter, daily (kWh)
Energy counter, weekly (kWh)
Energy counter, monthly (kWh)
G U-L1N (voltage L1-N)
G U-L2N (voltage L2-N)
G U-L3N (voltage L3-N)
G U-L1L2 (voltage L1-L2)
G U-L2L3 (voltage L2-L3)
G U-L3L1 (voltage L3-L1)
G U-Max (voltage max.)
G U-Min (voltage min.)
DEIF A/S
Display and menu structure
For bus/mains
M f-L1 frequency L1 (Hz)
M f-L2 frequency L2 (Hz)
M f-L3 frequency L3 (Hz)
Mains active power (kW)
Mains reactive power (kVAr)
Mains apparent power (kVA)
Power factor
Voltage angle between L1-L2 (deg.)
Voltage angle between L2-L3 (deg.)
Voltage angle between L3-L1 (deg.)
BB U-L1N
BB U-L2N
BB U-L3N
BB U-L1L2
BB U-L2L3
BB U-L3L1
BB U-MAX
BB U-Min
BB f-L1
BB AngL1L2-180.0deg
BB-M Ang -180.0deg
U-Supply (power supply V DC)
Energy counter, total (kWh)
Energy counter, daily (kWh)
Energy counter, weekly (kWh)
Energy counter, monthly (kWh)
M U-L1N (voltage L1-N)
M U-L2N (voltage L2-N)
M U-L3N (voltage L3-N)
M U-L1L2 (voltage L1-L2)
M U-L2L3 (voltage L2-L3)
M U-L3L1 (voltage L3-L1)
M U-Max (voltage max.)
M U-Min (voltage min.)
Page 19 of 24
